| Components | Details |
| PC system | Industrial Board | Seavo/ Gigabyte/Advantech H61 |
| CPU | Intel Dual Core I5 |
| RAM | GB |
| HDD | 500G |
| Interface | 6 RS-232 Ports;1 LTP;6 USB Ports,1 10/1000M Net Port ;Integrated Net Card, Sound Card |
| PC Power Supply | HUNTKEY/Great Wall |
| LCD monitor | Screen Size | 17 inch ( optional from 8inch to 65inch) |
| Brightness | 250cd/m2 |
| angle | horizontal 100°above;Vertical 80°above |
| Contrast | 1000:1 |
| Backlight tube life | more than 40,000hours |
| Max. resolution | 1280×1024 |
| Touch screen | Screen Size | 17 inch Diagonal ( optional from 8inch to 65inch) |
| Resolution | 4096x4096 |
| High Transparence, high precision and durability,Orientation precision< 2mm(0.080 inch);pure tempered glass;Single-point touch Life expectancy more 50,000,000 times |
| Receipt Printer | Interface | High Speed USB |
| Resolution | 4800*1200 maximum |
| Printing speed | 4.8 ipm |
| Width | 58 /80 /112 mm |
| Length | Customizable |
| Dot matrix printer | Printing method | 9 pins serial impact dot matrix |
| Printing Speed | 4.4lines/sec |
| Printing density | 210 dots(whole dots)/420 dots (half dots) |
| Detection Method | Paper out alarm,Overheat protection,Black mark printing |
| Paper | High quality 1 layer ordinary continuous paper or 2-3 layers copy paper;76±0.5 mm width;Thickness:Single-layer paper thickness 0.06-0.085mm,Multi-layer paper thickness: 0.05-0.08mm,Total thickness <0.20mm. |
Webcam | Resolution | 1280*720 |
| Pixel | 8000000 |
| Adaptive Resolution | 1280*720 |
| Interface | USB 2.0 |
| Driver | No |
| Encrypting Pinpad | Keylift‐span | 2,000,000 cycles |
| Key force | 2~3N |
| Key trip | >2.5mm |
| Protection level | IP65 |
| Operating Temperature | 0° C to 40° C |
| Motorized card reader | Interface | RS232 |
| Card Type | Support Magcard, IC Card, RF Card, Mifare S50,S70,UL Card |
| Magnetic Head Life | 500,000/min |
| 500,000/min | 300,000/min |
| Power Voltage | DC 24V±5% |
| Cash acceptor | Validation Rate | 98% or higher |
| Banknote size | Width: 62or 71mm; Length:120-160mm |
| Detection ability | High detection of forged bills |
| Bill Escrow | one bill |
| Cashbox capacity | 1000 banknotes max |
| Operating Voltage | 12V DC or 24V AC |
| Operating Temperature | 0° C to 55 ° C (12 V DC platform); -18° C to +60 ° C (24 V AC platform) |
| Card dispenser | Interface | RS232 |
| Card specification | 86mm×54mm×0.2-1.8mm |
| Working environment | From -30°C to 70°C |
| Contactless card reader | Status Display | LED indicator to show the power or communication status |
| Card Type | ISO14443TypeA of Contactless IC Card, including Mifare S50,Mifare S70,MF1ICL10,Mifare Pro,Mifare desfire,Mifare ultralight |
| Type | Support ISO14443 |
| Cheque scanner | Image scan
| Range:A6 size(105mm),Duplex scan |
| Method:Color CIS(control image sensor) |
| Method:Color CIS(control image sensor) |
| Speed:500mm/s |
| MICR recognition | E138 & CMC7 |
| Interface | RS232, USB |
| UPS | Input voltage | 145-290 V |
| Output voltage | 200-255 V |
| Output frequency | 50±0.5Hz |
| Transient time | 50±0.5Hz |
| Max time for supplying a single PC | 3~20minutes (for single PC) |
| Wireless module | 3G module | 1, Compatible with HSUPA, HSDPA, UMTS, EDGE, GPRS, GSM network
2, Browsing Internet at high speed of 7.2Mbps downlink and 5.76Mbps uplink rate in max
3, Sending and receiving short messages
4, Managing contacts
Interface: USB2.0, and USB1.1 compatible
Data transmission: Transmission rate will be depended on the live network |
| Alarm system sensor / IO control board | Function | Door alarm sensor with enternet function, SIM,SMS,CALL |
| Speakers | Features | Dual channel amplified speakers for Stereo ,8Ω 5W |
| Digital Power Supply | AC input voltage range | 100~240VAC |
| Frequency | 50Hz to 60Hz |
| AC input voltage range | 100~240VAC |
| Frequency | 50Hz to 60Hz |
| Accessories | Wire-lan port, USB ports, speakers, fans, cables, screws, etc. |
| Operation System | Windows 7 or Windows XP operation system without license |
| Free standing Cabinet | Durable steel frame, Slim and smart design; Easy to install and operate; Moisture proof,Antirust,Anti-acid,Anti-dust,Static free, have color and LOGO upon request. |
| Package | Security Packing method with bubble foam and wooden case |
